AMD Ryzen 7 5800X Desktop Processor
4th Gen Desktop Processor
4.7 GHz Max Boost Clock
36 MB Total Cache
8 Cores 16 Threads
Unlocked Processor
Processor Generation – 4th Generation
Processor Model Number – Ryzen 5800X
Cores & Threads – 8 Cores & 16 Threads
CPU Clock Speed – 3.8 GHz Base
CPU Socket – AM4 Socket
Cache Memory – 4 MB L2 & 32 MB L3
OVERVIEW
Powered by the Zen 3 architecture (which tends to provide increased instructions per cycle), the Ryzen 7 5800X offers impressive advantages in all computing applications, especially in the past in video gaming, video editing, streaming, etc. Exactly compared to the -gene model. Hence, it is a reasonable response processor for desktops. AMD’s Ryzen 7 5800X processor is an eight-core processor with solid single and multi-threaded ratings.
It offers great performance in video gaming along with other computing applications. But what is the attractive buying point of this chip in favor of a less-expensive counterpart or similar gaming performance over other AMD processors? Three key technologies – (a) AMD Ryzen Master Utility, (b) AMD StoreMI Technology, and (c) AMD Ryzen VR-Ready Premium – are duly supported with this chip for greater responsiveness.
It is a power-efficient over-clocking chip supported by a 400/500-series compatible board for PCIe Gen 4 and IPC gain (to increase frequency) and fit or support. Like all other processors in the AMD family, this fourth-generation 8-core chip is also equipped with eight cores, 3.8 GHz (speed-turbo 4.7 GHz), and sixteen threads with 105W TDP, 36MB cache, 128GB maximum memory support. to provide a warranty period of three years), etc.
But what makes it special in that high price range? Here at this microchip, the precise boost clock rate across the board is higher than expected.
TECHNICAL SPECIFICATIONS
General Specifications_
Platform_ Boxed Processor
Product Family_ AMD Ryzen Processors
Processor Generation_ 4th Gen
Former Codename_ Vermeer
CPU Socket_ AM4
No. of CPU Cores_ 8
No. of Threads_ 16
Base Clock_ 3.8GHz
Max. Boost Clock_ Up to 4.7GHz
L2 Cache_ 4MB
L3 Cache_ 32MB
Default TDP_ 105W
Processor Technology for CPU Cores_ TSMC 7nm FinFET
Unlocked for Overclocking_ Yes
Thermal Solution (PIB)_ Not included
Max. Operating Temperature (Tjmax)_ 90°C
*OS Support_ Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity_
PCI Express Version_ PCIe 4.0
System Memory Type_ DDR4
System Memory Specification_ Up to 3200MHz
Graphics Capabilities_
Integrated Graphics_ No
Graphics Model_ Discrete Graphics Card Required
Product IDs_
Product ID Boxed_ 100-100000063WOF
Product ID Tray_ 100-000000063
Key Features_
Supported Technologies_ AMD “Zen 3” Core Architecture
AMD StoreMI Technology
AMD Ryzen Master Utility
AMD Ryzen VR-Ready Premium
Specification: AMD Ryzen 7 5800X Desktop Processor
Product Type_
Processor
CPU SOCKET_
AM4
CPU PLATFORM_
AMD
Brand_
AMD
PROCESSOR SERIES_
Ryzen 7
PROCESSOR GENERATION_
7TH
PROCESSOR CORES_
8-Core
THREADS_
16
CACHE_
32 MB
INTEGRATED GRAPHICS_
NO
SPEED_
3.8 GHz
TURBO SPEED_
4.7 GHz
PERFORMANCE_
GAMING
IDEAL FOR GAMING_
YES
WARRANTY_
3 Years Warranty
