DeepCool CC560 | ATX | Mid-Tower Cabinet
Mid Tower Case Type
Mini-ITX/Micro-ATX/ATX MB Compatibility
4×120 mm Pre-installed Fans
Max 370 mm GPU Length
Max 163 mm CPU Cooler Height
OVERVIEW
The Deepcool CC560 mid-tower case offers excellent value with huge component compatibility, a full-size tempered glass window, and a total of four pre-installed LED fans that start any building right and fit well throughout the chassis. Ventilated, the CC560 sports an airflow front panel and a large mesh top panel to ensure fresh air circulation.
The Deepcool CC560 has a total of 4 pre-installed LED fans to ensure great airflow performance, ensuring any system build is receiving top cooling efficiency and has enough room to support a high-performance AIO liquid cooler which has a 360mm radiator upfront or 240mm at the top Cooling fan supports up to 6x 120mm or 4x 140mm.
FEATURES:
The DeepCool CC560 WH Mid-Tower Case in black offers exceptional worth with extensive part similarity, a regular treated glass window, and a sum of four pre-introduced LED fans that kick any form off right.
Abundant Airflow Performance – Very much ventilated all through the whole suspension, the Deepcool CC560 mid-tower case sports a wind stream front board and a huge lattice top board to guarantee natural air is flowing.
Primed and Ready – The sum of 4 pre-introduced LED fans guarantees large wind flow performance which ensures top-notch cooling capacity.
Wide Cooling Support – Adequate room to help elite execution AIO fluid coolers with space for 360mm radiators in front or 240mm on top.
Storage Solutions – Introduce up to 2x 2.5-inch SSDs straightforwardly on the backplate and 2x 3.5-inch HDDs under the cover in a removable drive confine for flexibility.
TECHNICAL SPECIFICATIONS
Part Number- R-CC560-BKGAA4-G-1
Motherboard Support- Mini-ITX / Micro-ATX / ATX
Materials used- ABS+SPCC+Tempered Glass
Power Supply Type- ATX PS2 (maximum length: 170mm)
Expansion Slots- 7 Slots
Front input/output Ports- 1 x USB 3.0, 1 x USB 2.0, 1 x Audio
3.5-inch Drive Bays- 2
2.5-inch Drive Bays- 2+1
Pre-Installed Fans- Front: 3 × 120 mm
Rear: 1 × 120 mm
Fan Support- Front: 3 × 120 / 2 × 140 mm
Top: 2 × 120 / 2 × 140 mm
Rear: 1 × 120 mm
Radiator Support- Front: 120/140/240/280/360 mm
Top: 120/240 mm
Rear: 120 mm
CPU Cooler Height Limit- 163 mm
GPU Length Limit- 370 mm
Product Dimensions (L × W × H)- 416 × 210 × 477 mm
Net Weight- 5.25 Kg
Product Type
PC Cabinets
EAN, GTIN, UPC
6933410000000
Brand
Deep Cool
COLOR
BLACK
FORM FACTOR
MID TOWER
MATERIAL
ABS, SPCC, TEMPERED GLASS
SIDE PANEL
TEMPERED GLASS
MOTHERBOARD COMPATIBILITY
ATX, MICRO-ATX, MINI-ITX
LIGHTING
LED
FANS
4
RADIATOR COMPATIBILITY
YES
IDEAL FOR GAMING
YES
WARRANTY
1 Year WarrantyProduct Type
PC Cabinets
EAN, GTIN, UPC
6933410000000
Brand
Deep Cool
COLOR
BLACK
FORM FACTOR
MID TOWER
MATERIAL
ABS, SPCC, TEMPERED GLASS
SIDE PANEL
TEMPERED GLASS
MOTHERBOARD COMPATIBILITY
ATX, MICRO-ATX, MINI-ITX
LIGHTING
LED
FANS
4
RADIATOR COMPATIBILITY
YES
IDEAL FOR GAMING
YES
WARRANTY
1 Year Warranty
