Fractal Design Meshify C Mini Dark TG m-ATX Gaming Cabinet

Brand Fractal Design
Series Meshify Series
Type Mini Tower
Color Black
Vendor Code FD-CA-MESH-C-MINI-BKO-TGD
3．5” or 2．5” Drive capacity 2
Dedicated 2．5” drive capacity 3
Expansion slots 5
Front ports 2x USB 3.0, Audio I/O, Power button, Reset button
Total fan mounts 7
Front fan 3x 120 mm or 2x 140 mm (1x Dynamic X2 GP-12 included)
Top fan 2x 120/140 mm
Rear fan 1x 120 mm (1x Dynamic X2 GP-12 included)
Bottom fan 1x 120 mm
Dust filters Bottom fan + PSU, Front fans, Top fans
Cable routing grommets Yes
Fixed velcro straps Yes
Captive thumbscrews Both side panels, SSD brackets
Left side panel Tempered glass panel
Right side panel Steel
Power supply type ATX
Motherboard compatibility mATX, ITX
Front radiator 120/240 mm, 140/280 mm (max width 144 mm)
Top radiator 120/240 mm (max component height on motherboard 40 mm)
Rear radiator 120 mm (max width 125 mm)
Max PSU length 175 mm
Max GPU length 315 mm with front fan mounted
Max CPU cooler height 172mm
Cable routing space 15-35 mm
Case dimensions (LxWxH) 395 x 212 x 399 mm
Net weight 6.28 kg
Package Dimensions (LxWxH) 502 x 295 x 484 mm
Package weight 7.41 kg
Volume 33.4 Liters
3．5” Bays 2
2．5” Bays 3
Max Radiator Support 280
Max Fan Support 7
Side Panel Transparent
Warranty 2 Years
