Fractal Design Prisma AL-12 120mm ARGB PWM Cabinet Cooling Fan
Prisma AL-12/PWM
Our Prisma AL Series ARGB fans allow your system to truly shine. Six hub-mounted addressable RGB LEDs work in harmony with a white semi-opaque outer ring and fan blades to produce a beautifully uniform glow across the fan’s entire surface.
Supports Gigabyte Fusion, ASUS Aura, Razer Chroma, MSI Mystic Light and ASRock Polychrome
Prisma AL-12/14 allows precision software control, enabling Prisma to synergize perfectly with your components. If you prefer physical control, just pair Prisma with the newly released Adjust R1 controller to set colors, brightness, and motion effects with the push of a button.
As with any Fractal Design fan, silence remains a central focus with integrated vibration damping corners, silent LLS bearings, and PWM options for complete control over the speed of your fans, ensuring Prisma is seen, not heard.
Let your system shine
Support for ASUS Aura, Gigabyte Fusion, MSI Mystic Light and ASRock Polychrome allows precision software control, enabling Prisma to synergize perfectly with your components.
Six individually addressable hub-mounted RGB LEDs
Specially designed fan blades and outer ring produce an exceptionally uniform glow
Chainable RGB cables simplify wiring and make the most of available connections
Black sleeved power cables offer an extra touch of style
Asus AURA, Gigabyte Fusion, MSI Mystic Light, and ASRock Polychrome support
Adjust R1 RGB controller (sold separately) enables physical control of colors and effects
Available in 3-pack
Aerodynamic performance
Aerodynamic stator struts with embedded wiring reduce noise and turbulence
Trip Wire technology introduces a micro-turbulent layer for enhanced blade efficiency
Integrated vibration-damping corners made from high-quality synthetic rubber
LLS (Long Life Sleeve) bearings provide silent operation with a long lifespan
Technical Details
Brand : Fractal Design
Model : FD-FAN-PRI-AL12-PWM-3P
Specifications
Size : 120 x 120 x 25 mm
Screw hole pattern : 105 x 105 mm
Fan connector : 4-pin PWM
RGB connector : 3-pin 5V addressable RGB
Bearing : LLS
Number of blades : 7
Rotational speed : 500 – 2000 RPM
Noise level : 32.7 dB(A)
Airflow (CFM) : 85.71 CFM
Airflow (m3/h) : 145.62 m3/h
Static pressure : 2.78 mmH2O
Fan input power : 2.16 W
Fan max input current : 0.18 A
Fan input voltage : 12 V
Fan starting voltage : 7 V
LED input power : 1.50 W
LED max input current : 0.30 A
LED input voltage : 5 V
Low (0-20%) PWM speed : 500 RPM
Low PWM noise level : 14.8 dB(A)
Low PWM airflow : 20.68 CFM
Low PWM static pressure : 0.36 mmH2O
MTBF ; 100,000 hours
Fan weight : 169 g
Cable length : 500 mm
Cable type : Black sleeved
Other
Package contents : Prisma AL-12 PWM 140 mm fan, 4 x fan screws / 3x Prisma AL-12 PWM 140 mm fan, 12x fan screws (3-pack)
Package weight : 592 g (3-pack)
Package dimensions (Including hanging tab) : 202 x 122 x 80 mm (3-pack)
Package dimensions (Excluding hanging tab) : 157 x 122 x 80 mm (3-pack)
