Fractal Design Vector RS ATX Mid Tower Cabinet FD-C-VER1A-02
With customizable effects, adaptable layout, and interchangeable elements, Vector becomes what you want it to be: The perfect showcase for your system.
With customizable effects, adaptable layout, and interchangeable elements, Vector becomes what you want it to be: The perfect showcase for your system.
• Tinted, bolt-free tempered glass on three sides
• Top panel easily converts between tempered glass and filtered ventilation
• Counter-angled vents designed to trap noise with minimal airflow resistance
Command attention
Sharp angles, uncompromising design and a no-nonsense attitude combine to create a case quite unlike any other. Just look at the expressive ARGB strip or the counter-angled air intakes designed to trap noise without restricting airflow, giving you a case that breathes like it’s open – but sounds like it’s closed.
Attractive aesthetics
Tinted, bolt-free tempered glass on three sides
Top panel easily converts between tempered glass and filtered ventilation
Customizable ARGB LED effects wrapping top and front panels in a synchronized span
Control via standard 5V RGB motherboard connection or included Adjust R1 controller
Compatible with standard 5V RGB motherboard connectors and software
Push-to-lock latching for quick side panel access on both sides
Extensive water-cooling support
The Vector RS is designed to offer you a wide range of options for your water-cooling setup.
Front radiator: Up to 360/280 mm
Top radiator: Up to 360/420 mm (with cooling bracket installed)
Rear radiator: 120 mm
Bottom radiator: Up to 240/280 mm
Vertically inclined
Vertical 2.5 slot GPU support via Flex vertical PCIe riser (sold separately)
Full speed ahead
USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps
Conceal and expand
Ventilated PSU shroud conceals cables and provides additional SSD mounting options
Dual layout design
Converting between Open and Storage layout is both fast and easy, ensuring you always get the very most out of your Vector RS.
Six HDD and two SSD mounts included with a total of 11 HDD and 4 SSD positions (additional Type A brackets sold separately)
Modular design easily converts from a storage-focused standard layout to a cooling-centric open layout
Six vibration damped 3.5” HDD trays and two 2.5” SSD brackets included
Universal HDD/SSD trays can be independently repositioned to suit your configuration
A new cooling angle
Thanks to the counter-angled intake vents, the Vector RS is a case that can breathe like it’s open, but sound like it’s closed.
Designed to trap noise with minimal airflow resistance
Three pre-installed Fractal Design Dynamic X2 GP-14 140 mm fans for optimal airflow
Up to nine fan positions with clear airflow paths for maximum cooling capacity
Nexus+ fan hub manages up to nine fans via your motherboard
High-density industrial sound damping bitumen on the right-hand side panel
Easy-to-clean high-airflow nylon filters on the front, top and base
Supports Gigabyte Fusion, ASUS Aura, Razer Chroma, MSI Mystic Light and ASRock Polychrome
Specification :
3.5″/2.5″ Universal drive brackets 6 included, 11 positions total
Dedicated 2.5″ drive brackets 2 included, 4 positions total
Expansion slots 7 + 2 vertical
Front ports 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, Audio
Total fan mounts 9 (6 + 3 with included bracket)
Front fan 3 x 120/140 mm (2 x Dynamic X2 GP-14 included)
Top fan 3 x 120/140 mm (with cooling bracket installed)
Rear fan 1 x 120/140 mm (1 x Dynamic X2 GP-14 included)
Bottom fan 2 x 120/140 mm
Dust filters Bottom fan + PSU – Front fans – Top panel (with cooling bracket installed)
Fixed velcro straps Yes
Cable routing grommets Yes
Captive thumbscrews HDD brackets, SSD brackets
Additional Lighting Integrated front/top panel ARGB
Left side panel Dark tint tempered glass
Right side panel Steel with bitumen sound damping
Compatibility
Motherboard compatibility EATX (up to 285 mm wide) / ATX / mATX / ITX
Power supply type ATX
PSU max length 300 mm
GPU max length 440 mm with front fan installed
CPU cooler max height 185 mm
Front radiator 120/240/360 mm – 140/280 mm
Top radiator With cooling bracket installed: – 120/240/360 mm – 140/280/420 mm (max 35 mm motherboard component height)
Rear radiator 120 mm
Bottom radiator 120/240 mm – 140/280 mm
Cable routing space 23 mm
Vertical GPU Support (with Flex VRC-25) 31mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling
Dimensions
Case dimensions (LxWxH) 552 x 233 x 498 mm
Case dimensions w/o feet/protrusions/screws 540 x 233 x 475 mm
Package dimensions (LxWxH) 568 x 328 x 673 mm
Net weight 12.64 kg
Package weight 13.98 kg
Other
Package contents Vector RS Blackout Dark computer case, 3x Dynamic X2 GP-14 Fans, Ventilated top panel, Top filter, Top radiator/fan bracket, Adjust R1 RGB controller, User manual, Accessory box,
Product code FD-C-VER1A-02
