Gigabyte B365M Aorus Elite Motherboard

Model – B365 M AORUS ELITE

CPU – Intel LGA1151

Chipset – Intel B365

Memory – DDR4

Graphics Output Options – DVI-D, D-SUB, HDMI

Recommended reading:ASRock B450M/AC AM4 Micro ATX AMD Motherboard

OVERVIEW
The AORUS B365 platform supports Intel’s latest Optane technology. Acting as a cache drive, Upton fuels storage performance which gives users a significant increase compared to traditional mechanical drives. Intel GbE LAN features cFosSpeed, a network traffic management application that helps improve network latency and maintain less ping time to better respond to crowded LAN environments. The AORUS motherboard is even better with RGB Fusion 2.0 addressable LEDs.

Already full of color and pattern, the RGB Fusion 2.0 on the B360 series AORUS motherboard has now been upgraded with addressable LED support. With external Addressable LED strips, where each LED is digitally addressable, users can experience more patterns, styles, and illuminations. The AORUS motherboard will support a 5v or 12v Addressable LED light strip and up to 300 LED lights. RGB Fusion 2.0 with addressable LEDs brings new patterns and more with different speed settings.

TECHNICAL SPECIFICATIONS

Model_B365 M AORUS ELITE
CPU_Support for 9th and 8th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package
L3 cache varies with CPU
Chipset_Intel B365 Express Chipset
Form Factor_Micro ATX Form Factor; 24.4cm x 24.4cm
Memory_4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
Dual-channel memory architecture
Support for DDR4 2666/2400/2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
* To support 2666 MHz or XMP memory, you must install a 9th or 8th Generation Intel® Core™ i9/i7/i5 processor.
BIOS_2 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
Support for DualBIOS™
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Graphics_Integrated Graphics Processor-Intel HD Graphics support:
1 x DVI-D port, supporting a maximum resolution of 1920×1200 60 Hz
* The DVI-D port does not support a D-Sub connection by adapter.
1 x DisplayPort, supporting a maximum resolution of 4096×2304 60 Hz
* Support for DisplayPort 1.2 version, HDCP 2.2, and HDR.
1 x HDMI port, supporting a maximum resolution of 4096×2160 30 Hz
* Support for HDMI 1.4 version and HDCP 2.2.
Support for up to 3 displays at the same time
Maximum shared memory of 1 GB
Audio_Realtek ALC892 codec
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN_Intel GbE LAN chip (10/100/1000 Mbit)
Slots_1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
1 x PCI Express x1 slot
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)
Storage_1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2Q)
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2A)
6 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10
* Refer to “1-7 Internal Connectors,” for the installation notices for the M.2 and SATA connectors.
Intel Optane Memory Ready
Connector_1 x PS/2 keyboard/mouse port
1 x DVI-D port
1 x DisplayPort
1 x HDMI port
1 x USB Type-C port, with USB 3.1 Gen 1 support
3 x USB 3.1 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks
Internal I/O Connectors_1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
2 x addressable LED strip headers
2 x addressable LED strip power select jumpers
2 x RGB LED strip headers
6 x SATA 6Gb/s connectors
2 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.1 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)
1 x serial port header
1 x Clear CMOS jumper
Bundled Software Norton Internet Security (OEM version) cFosSpeed
I/O Controller_iTE I/O Controller Chip
Hardware Monitor_Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
OS_Support for Windows 10 64-bit
USB_1 x USB Type-C port on the back panel, with USB 3.1 Gen 1 support
5 x USB 3.1 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)
6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Multi-Graphics Technology_Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies
Unique Feature_Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
3D OSD
BIOS
AutoGreen
Cloud Station
EasyTune
Easy RAID
Fast Boot
Game Boost
ON/OFF Charge
Platform Power Management
RGB Fusion
Smart Backup
Smart Keyboard
Smart TimeLock
Smart HUD
Smart Survey
System Information Viewer
USB Blocker
Support for Q-Flash
Support for Xpress Install
Product Dimension_25 x 6 x 34.5 cm
Weight_1 kg
Specification: Gigabyte B365M Aorus Elite Motherboard
Brand
Gigabyte

WARRANTY
3 Years Warranty

Recommended reading:Gigabyte H410M S2H Gaming Motherboard

Product Type
Motherboards

CPU PLATFORM
INTEL

CPU SOCKET
LGA1151

FORM FACTOR
MICRO-ATX

MEMORY TYPE
DDR4
