Gigabyte H61M-S m-ATX Motherboard

Model – GA-H61M-S

CPU – LGA 1155

Chipset – Intel H61

LAN – Realtek GbE LAN chip

Form Factor – Micro ATX Form Factor

Recommended reading:ASRock TRX40 Creator WiFi ATX Motherboard | AMD Ryzen Threadripper Series CPU Support | AMD sTRX4 Socket | Max 256GB Memory Support

TECHNICAL SPECIFICATIONS

Model_GA-H61M-S
CPU_Support for Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1155 package
L3 cache varies with CPU
Chipset_Intel H61 Express Chipset
Form Factor_Micro ATX Form Factor; 19.0cm x 17.0cm
Memory_2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
Dual-channel memory architecture
Support for DDR3 1333/1066/800 MHz memory modules
Support for non-ECC memory modules
Support for Extreme Memory Profile (XMP) memory modules
* To support XMP memory, you must install an Intel® 22nm (Ivy Bridge) CPU.
BIOS_1 x 32 Mbit flash
Use of licensed AMI EFI BIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a
Graphics_Integrated Graphics Processor:
1 x D-Sub port
Maximum shared memory of 1 GB
Audio_Realtek ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
LAN_Realtek GbE LAN chip (10/100/1000 Mbit)
Slots_1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conforms to PCI Express 3.0 standard.)
* Whether PCI Express 3.0 is supported depends on CPU and graphics card compatibility.
1 x PCI Express x1 slot
(The PCI Express x1 slot conforms to PCI Express 2.0 standard.)
Storage_Chipset:
4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
Internal I/O Connectors_1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
2 x USB 2.0/1.1 headers
1 x speaker header
1 x chassis intrusion header
1 x Clear CMOS jumper
I/O Controller_iTE I/O Controller Chip
Bundled Software_Norton Internet Security (OEM version)
Back Panel Connectors_1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
4 x USB 2.0/1.1 headers
1 x RJ-45 port
3 x audio jacks (Line In, Line Out, Mic In)
USB_Chipset:
Up to 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Hardware Monitor_System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU/System fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
OS_Support for Windows 8.1/8/7/XP
Unique Feature_Support for BIOS
Support for Q-Flash
Support for Xpress Recovery2
Support for EasyTune
* Available functions in EasyTune may differ by motherboard model.
Support for ON/OFF Charge
Product Dimension_19.0cm x 17.0cm
Specification: Gigabyte H61M-S m-ATX Motherboard
Product Type
Motherboards

EAN, GTIN, UPC
4719331825201

CPU PLATFORM
INTEL

CPU SOCKET
LGA1155

Recommended reading:MSI Prestige X570 Creation E-ATX Gaming Motherboard

FORM FACTOR
MICRO-ATX

Brand
Gigabyte

CHIPSET
Intel H61

MAXIMUM MEMORY
16 GB

IDEAL FOR GAMING
NO

Recommended reading:ASRock B450M-HDV R4.0 Gaming Motherboard

WARRANTY
3 Years Warranty
