NZXT H500I ATX Mid Tower Cabinet – Matte Black

The H500i compact mid-tower case features a unique CAM-powered Smart Device that digitally drives RGB lighting and fan performance. You can effortlessly control RGB lighting and fans, while Adaptive Noise Reduction optimizes your build’s acoustics delivering ideal fan settings through machine learning. Includes two Aer F fans* and two RGB LED strips to enhance the aesthetics of your build as seen through the H500i’s stunning tempered glass panel.

Specification :

Dimensions W: 210mm H: 435mm D: 428mm (without feet)
W: 210mm H: 460mm D: 428mm (with feet)
Material(s) SECC Steel and Tempered Glass
Weight 7 kg
Motherboard Support Mini-ITX, MicroATX, and ATX
I/O Ports 2 x USB 3.1 Gen 1
1 x Audio/Mic
Filters Front right side panel, bottom front and PSU intake
Expansion Slots 7
Smart Device 3 x Fan channels with Max 10W per channel output*
1 x RGB LED port support up to 4 x HUE LED strips or 5 x Aer RGB fans
Built-in noise detection module
*Note: If a splitter is used, fan control is regulated depending on the fan connected to the 4-pin port. Do not use low-noise adapters.
System Requirements PC with open internal USB 2.0 port and Windows® 10 operating system recommended.
Internet connection is needed to download CAM.Some CAM features require Internet access, a valid email address and acceptance of our current Terms of Service.
Vertical GPU Mount Support 2 slot GPUs
Riser card with 30cm length recommended. Riser card not included.
Drive Bays 2.5”: 2 1
3.5”: 2 1
Radiator Support Front: Up to 280mm
Rear: 120mm
Fan Support Front: 2 x 120/2 x 140mm
Top: 1 x 120mm (1 Aer F120 Case Version included) / 1 x 140mm
Rear: 1 x 120mm (1 Aer F120 Case Version included)
Fan Specs Aer F120 (Case Version)
Speed: 1200 200 RPM
Airflow: 50.42
CFM Noise: 28 dBA
Bearing: Rifle Bearing
Clearance Cable Management: 19-23mm
GPU Clearance: Up to 381mm
CPU Cooler: Up to 165mm
Front Radiator: 60mm
Rear Radiator: 60mm
Reservoir & Pump: Up to 180mm (Along cable bar), Up to 86mm (Along bottom panel)
Warranty 2 Years
Model Number CA-H500W-B1
EAN 5060301694099
UPC 815671013781
