NZXT H510 Flow Mid Tower Gaming Cabinet – CA-H52FW-01 | 2 x 120mm Fans Pre-Installed | Tempered Glass Side Panel – Matte White
Mid Tower Case Type
Mini-ITX/Micro-ATX/ATX Motherboard Support
Tempered Glass Side Panel
Up to 360mm GPU Clearance Length
Up to 280mm Radiator Support
Case Type – Mid Tower
Motherboard Compatibility – ATX, Micro-ATX, Mini-ITX
Case Material – SGCC Steel, Tempered Glass
CPU Cooler Clearance – Up to 165mm
GPU Clearance – Up to 360mm
OVERVIEW
The NZXT H510 Flow Mid Tower Gaming Cabinet is a concise and simple design with a sleek and professional look. The H510 offers a large transparent panel window so you can see your components and cables inside the case. The H510 side panel is designed to be as cool as possible with a clever sound damp material. The H510 also offers two pre-installed fans with a total of four fan slots. This case has a cable handling system that helps you organize and keep your cables away. There is a dust filter on the front which helps to keep your case clean and dust-free.
TECHNICAL SPECIFICATIONS
General–
Model– CA-H52FW-01
Color– Matte White
Motherboard Support– Mini-ITX, Micro-ATX, ATX
Case Type– Compact Mid-Tower
Case Material– SGCC Steel, Tempered Glass
Compatibility & Clearance–
Max CPU Cooler Clearance– 165 mm
Max GPU Clearance– 360 mm
Front Fan & Radiator Clearance– 60 mm
Cable Management– 19 mm – 23 mm
Front I/O Ports–
USB 3.2 Gen 1 Type-A– 1
USB 3.2 Gen 2 Type-C– 1
Headset Audio Jack– 1
Expansion Slots–
Standard– 7
Vertical– None
Drive Bays–
2.5 inch– 2 + 1
3.5 inch– 2 + 1
Fan Support–
Front– 2 x 140 mm / 2 x 120 mm
Top– 1 x 140mm / 1 x 120mm
Rear– 1 x 120 mm
Filters– All air intakes
Included Fans–
Front– 1 x Aer F 120 mm (Case Version)
Top– None
Rear– 1 x Aer F 120 mm (Case Version)
Pre-Installed Fan Specs–
Model– Aer P 120 mm x 2 (Case Version)
Speed– 1,200 ± 200RPM
Airflow– 50.42 CFM
Noise– 28 dBA
Fan Connector– 3-pin
Radiator Support–
Front– 280 mm
Top– None
Rear– 120 mm
Dimensions & Weight–
Height– 460 mm / 18.11 inches
Width– 210 mm / 8.26 inches
Depth– 428 mm / 16.85 inches
Weight– 6.6 kg / 14.55 lb
Specification: NZXT H510 Flow Mid Tower Gaming Cabinet – CA-H52FW-01 | 2 x 120mm Fans Pre-Installed | Tempered Glass Side Panel – Matte White
EAN, GTIN, UPC–
5060301699254
WARRANTY–
2 Years Warranty
Product Type–
PC Cabinets
Brand–
NZXT
COLOR–
MATTE WHITE
FORM FACTOR–
MID TOWER
MATERIAL–
SGCC, STEEL, TEMPERED GLASS
SIDE PANEL–
TEMPERED GLASS
MOTHERBOARD COMPATIBILITY–
ATX, MICRO-ATX, MINI-ITX
LIGHTING–
NONE
FANS–
2
RADIATOR COMPATIBILITY–
YES
IDEAL FOR GAMING–
YES
