PNY Nvidia Quadro RTX A4000 16GB GDDR6 Graphics Card
16GB GDDR6 GPU Memory
256-bit Bus Memory
PCI-Express 4.0×16 Interface
Maximum 4 Display Support
448 GB/s Memory Bandwidth
GPU Interface – PCI Express 4.0 x16
Memory – 16 GB GDDR6
CUDA Cores – 6144
Memory Bandwidth – 448 GB/s
Memory Bus – 256-bit
Maximum Display Support – 4
OVERVIEW
The NVIDIA Ampere architecture builds on the power of NVIDIA RTX to deliver the next generation of accelerated visual computing. As millions of professionals continue to work from anywhere, they rely on a wide range of equipment to deliver the power and performance they need to work effectively.
The NVIDIA RTX A4000 is the most powerful single-slot GPU for professionals, delivering real-time ray tracing, AI-accelerated computation, and high-performance graphics performance on your desktop.
Built on the NVIDIA Ampere architecture, the RTX A4000 GPU packs 16GB of graphics memory along with 48 second-generation RT cores, 192 third-generation Tensor cores, and 6144 CUDA cores. So you can design the next generation of products from your desktop workstation, design the cityscapes of the future, and create the fun entertainment experiences of yesterday, and today.
With a power-efficient, single-slot PCIe form factor that fits a wide range of workstation chassis, you can get exceptional work done without any limitation.
TECHNICAL SPECIFICATION
Architecture_ NVIDIA Ampere Architecture
Process Size_ 8nm
GPU Memory_ 16 GB GDDR6 with ECC
Memory Interface_ 256-bit
Memory Bandwidth_ 448 GB/sec
CUDA Cores_ 6144
Tensor Cores_ 192
RT Cores_ 48
System Interface_ PCI Express 4.0 x16
Transistors_ 17.4 Billion
Die Size_ 392.5 mm2
Single Precision Performance_ 19.2 TFLOPS
RT Core Performance_ 37.4 TFLOPS
Tensor Performance_ 153.4 TFLOPS
Display Connectors_ 4x DisplayPort 1.4a
NVENC | NVDEC_ 1x | 1x (+ AV1 decode)
Form Factor_ 4.4-inch x 9.5 inches (H x L) Single Slot
Thermal Solution_ Active Fansink
Maximum Power Consumption_ 140 W *NVIDIA Quadro and RTX Power Guidelines
Power Connector_ 1x 6-pin PCIe
Max Digital Resolution_ 7680 x 4320 x36 bpp at 60 Hz *NVIDIA Quadro and RTX Display Resolution Support
NVIDIA 3D Vision and 3D Vision Pro_ Support via 3-pin mini-DIN
Frame Lock_ Optional NVIDIA Quadro Sync II
Dimension_ 29.69 x 23.19 x 8.71 cm
Weight_ 962 gm (approx)
Specification: PNY Nvidia Quadro RTX A4000 16GB GDDR6 Graphics Card
Product Type_
Graphics Card
EAN, GTIN, UPC_
0816379023638
FORM FACTOR_
ATX , E-ATX
FANS_
1
Brand_
PNY
COLOR_
BLACK
CHIPSET_
NVIDIA
PROCESSOR SERIES_
NVIDIA QUADRO
CAPACITY_
16 GB
BIT RATE_
256
MEMORY TYPE_
GDDR6
LIGHTING_
NONE
WARRANTY_
3 Years Warranty
